Tamper Evident Labelling Machine

Tamper Evident Labelling

Tamper evident labelling machine is a high-performance machine with precise and automatic labelling to each side of the carton ensuring that the secure cartons leave the machine sealed with unique identity. A wide range of carton sizes can be handled at high speeds with 60- 300 cartons per minute. The track and trace feature will aid the cartons to be traced at any point during the increasingly complex world-wide supply chain for pharmaceutical products.


  • Tamper evident labelling machine
  • Tamper evident labelling machine
  • Tamper evident labelling machine

Applications

  • Tamper evident labelling machine
  • Tamper evident labelling machine
  • Tamper evident labelling machine

TECHNICAL SPECIFICATIONS

SPEED : 60-300 CARTONS PER MINUTE
ROLL O.D. : 350MM
LABEL MATERIAL : PAPER/FILM/PP/PE
LABEL DIMENSIONS : MIN:15MM X 25MM
MAX:20MM X 75MM
MOC : SS 304
POWER SUPPLY / CONSUMPTION : 220VAC/50HZ/SINGLE PHASE/2.0KW
OPERATING SYSTEM : MICRO CONTROLLER WITH KEYPAD / STEPPER PLC OR SERVO WITH TOUCH SCREEN
MACHINE DIMENSIONS : 1200MM X 950MM X 1500MM (L X B X H)
1500MM X 950MM X 1500MM (L X B X H) WITH TRACK AND TRACE
PRINTER : TIJ CAN BE INTEGRATED WITH THE MACHINE
APPLICATION : TAMPER EVIDENT ‘L’ SEAL ON MONO CARTONS
OPTIONAL : TUCK IN SINGLE SIDE / TUCK IN BOTH SAME SIDES / OPPOSITE SIDES
COVERED : IN DIAGONALLY OPPOSITE SIDES

STANDARD FEATURE

  • No change parts

    No change parts

  • Product count

    Product count

  • Safety cabinet with interlocks

    Safety cabinet with interlocks

  • 3 level password protection

    3 level password protection

  • Synchronised VFD’s for single point control

    Synchronised VFD’s for single point control

  • Precise ‘L’ seal for tamper evidence on tuck in type monocartons of single/double same side/double diagonally opposite side

    Precise ‘L’ seal for tamper evidence on tuck in type monocartons of single/double same side/double diagonally opposite side

  • Colour Touch Screen for easy accessibility

    Colour Touch Screen for easy accessibility

OPTIONAL FEATURES

  • On line inspection & rejection with camera of text and 2D barcode

    On line inspection & rejection with camera of text and 2D barcode

  • Electrical panel door interlock

    Electrical panel door interlock

  • Label roll end alarm

    Label roll end alarm

  • Jamming sensor

    Jamming sensor
